General Specifications
Hardware and
included
accessories
Device
Serial Server
CD
CD with Vlinx Manager software for
Win XP (32/64 bit), 2003 Server (32/64 bit), Vista (32/64 bit), 2008
Server (32/64 bit), Windows 7 (32/64 bit)
Optional
Accessories
Cable
232NM9 Null Modem Crossover Cable for DTE to DTE connection
DIN Rail
ERS35 one-meter length of steel 35mm DIN Rail
Configuration
Options
Via serial port
Using Vlinx Manager via a serial connection, (press Reset button to
enter Console Mode)
Via network
Using Vlinx Manager via a Ethernet connection
Using a standard web browser such as Internet Explorer or Firefox
Software
Vlinx Manager for
serial server
configuration
Win XP (32/64 bit), 2003 Server (32/64 bit), Vista (32/64 bit), Windows
7 (32/64 bit), Windows 2008 Server (32/64 bit)
Environment
Operating
Temperature
-40 to 80 °C (-40 to 176 °F)
Storage
Temperature
-40 to 85 °C (-40 to 185 °F)
Operating
Humidity
10 to 95% non-condensing
Maximum
Ambient
Surrounding Air
Temp
80 °C
Enclosure
Rating
IP 30, Metal
Mounting
DIN rail mount (35 mm)
Dimensions
5.5 x 3.5 x 1.4 in (13.9 x 8.7 x 3.5 cm)
Power Supply
Voltage
Requirements
10 to 48 VDC (58 VDC Maximum)
Power
Consumption
VESR321
– 4.0W (max)
Terminal Blocks
Wire Size
28 to 16 AWG
Wire Type
Copper Wire Only
Tightening Torque
5 KG-CM
Wire Temp Rating
105 °C Minimum, Sized for 60 °C Ampacity
Note:
One Conductor Per Terminal
Port to Port
Isolation
Serial to Ethernet
2 kV
Serial to Power
2 kV
Ethernet to Power
1.5 kV
Controls, Indicators and Connector Specifications
