Using ESP Manager
22 Chapter 4 Manual Documentation Number: ESP904-4513m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com

COM Name - Displays the name of the computer COM port mapped to
each Serial Server port. If no computer port has been mapped it displays
Not mapped.

Status - The Status indicates the mapped virtual COM port condition.
o
Not Connected is shown when a program does not have the
port Open.
o
Connected is shown when that mapped port is Open for use.
Virtual COM List

COM Name - Displays the number of the COM port mapped to each
Serial Server port.

IP Address - Displays the IP Address for the Serial Server . All ports in
a Serial Server have the same IP address.

Protocol - Displays the currently selected TCP or UDP mode for the
Serial Server .

Port - Displays the port number for each Serial Server port.

Flow Control - Indicates what type of flow control is configured for
each port.

Status - Indicates whether each port is currently In Use or Not Used.
Status Bar
Displays the current status of the software in the bottom, left corner of the screen

Ready

Updating
 Searching reachable servers…
Search for Servers
Upon opening the ESP Manager software it will automatically execute
Searching Server and search for all reachable ESP90x serial servers.
Step 4: To manually initiate a search for servers, click Searching Servers
(under the Servers menu or the icon on the left side of the screen).
The Search Setup box will appear.
It provides two options for searching for servers on the network:
 Specify the IP Address of the Serial Server
 Search all reachable servers
