ISOCON-6 USERS GUIDE
4.1.1 Voltage Input:
Select the range from the table below and set Switch S1 to the required values.
Voltage
Range
1 2 3 4 5 6 7 8 9 10 11 12
0-1V 0 0 0 0 0 1 0 0 1 1 0 0
0-2V 0 0 0 1 0
0-4V 0 0 1 0 0
0-5V 0 1 0 0 0
0-7.5V 1 0 0 0 0
0-8V 0 0 1 1 0
0-10V 0 1 0 1 0
0-15V 1 0 0 1 0
0-20V 0 1 1 0 0
0-30V 1 0 1 0 0
0-40V 0 1 1 1 0
1-5V 0 1 0 0 1
-5 to +5V 1 1 0 0 1
-10 to +10V 1 1 0 1 0 1 0 0 1 1 0 0
Switch S1
Then select the required setting from the table below for switch S2
Voltage Range
0-30V & 0-40V
Ranges 0 0 1 1 0 0 1 1 0 0 0 0
0 0 1 0 1 0 1 0 0 0 0 0
All other Ranges
Listed Above
Switch S2
!
1 2 3 4 5 6 7 8 9 10 11 12
! WARNING !
DO NOT OPEN UNIT OR ADJUST SWITCHES WITH
POWER SUPPLY, INPUT OR OUTPUT CONNECTED
Please note that PC Software is available to provide information on
switch settings for your input and output requirements.
