Note: 1. This parameter is characterized and is not 100% tested.
Note: 1. V
IL
min and V
IH
max are reference only and are not tested.
Pin Capacitance
(1)
Applicable over recommended operating range from T
A
= 25 °C, f = 1.0 MHz, V
CC
= +5.0V (unless otherwise noted).
Symbol Test Conditions Max Units Conditions
C
OUT
Output Capacitance (DO) 5 pF V
OUT
= 0V
C
IN
Input Capacitance (CS, SK, DI) 5 pF V
IN
= 0V
DC Characteristics
Applicable over recommended operating range from: T
AI
= -40 °C to +85°C, V
CC
= +2.7V to +5.5V,
T
AC
= 0
°C to +70°C, V
CC
= +2.7V to +5.5V (unless otherwise noted).
Symbol Parameter Test Condition Min Typ Max Unit
V
CC1
Supply Voltage 2.7 5.5 V
V
CC2
Supply Voltage 4.5 5.5 V
I
CC
Supply Current V
CC
= 5.0V
READ at 1.0 MHz 0.5 2.0 mA
WRITE at 1.0 MHz 0.5 2.0 mA
I
SB1
Standby Current V
CC
= 2.7V CS = 0V 6.0 10.0 µA
I
SB2
Standby Current V
CC
= 5.0V CS = 0V 17 30 µA
I
IL
Input Leakage V
IN
= 0V to V
CC
0.1 1.0 µA
I
OL
Output Leakage V
IN
= 0V to V
CC
0.1 1.0 µA
V
IL1
(1)
V
IH1
(1)
Input Low Voltage
Input High Voltage
4.5V ≤ V
CC
≤ 5.5V
-0.6
V
CC
x 0.7
V
CC
x 0.3
V
CC
+ 1
V
V
IL2
(1)
V
IH2
(1)
Input Low Voltage
Input High Voltage
V
CC
≤ 2.7V
-0.6
V
CC
x 0.7
V
CC
x 0.3
V
CC
+ 1
V
V
OL1
V
OH1
Output Low Voltage
Output High Voltage
4.5V ≤ V
CC
≤ 5.5V
I
OL
= 2.1 mA 0.4 V
I
OH
= -0.4 mA 2.4 V
V
OL2
V
OH2
Output Low Voltage
Output High Voltage
V
CC
≤ 2.7V
I
OL
= 0.15 mA 0.2 V
I
OH
= -100 µA V
CC
- 0.2 V
