17
AT25080A/160A/320A/640A
3401C–SEEPR–8/04
Packaging Information
8P3 – PDIP
2325 Orchard Parkway
San Jose, CA 95131
TITLE
DRAWING NO.
R
REV.
8P3, 8-lead, 0.300" Wide Body, Plastic Dual
In-line Package (PDIP)
01/09/02
8P3
B
Notes: 1.
This drawing is for general information only; refer to JEDEC Drawing MS-001, Variation BA, for additional information.
2.
Dimensions A and L are measured with the package seated in JEDEC seating plane Gauge GS-3.
3. D, D1 and E1 dimensions do not include mold Flash or protrusions. Mold Flash or protrusions shall not exceed 0.010 inch.
4.
E
and eA measured with the leads constrained to be perpendicular to datum.
5. Pointed or rounded lead tips are preferred to ease insertion.
6.
b2 and b3 maximum dimensions do not include Dambar protrusions. Dambar protrusions shall not exceed 0.010 (0.25 mm).
COMMON DIMENSIONS
(Unit of Measure = inches)
SYMBOL
MIN
NOM
MAX
NOTE
D
D1
E
E1
e
L
b2
b
A2 A
1
N
eA
c
b3
4 PLCS
A
–
–
0.210
2
A2 0.115
0.130 0.195
b 0.014
0.018 0.022 5
b2 0.045
0.060
0.070
6
b3 0.030 0.039 0.045 6
c 0.008 0.010 0.014
D 0.355 0.365 0.400 3
D1 0.005 –
–
3
E 0.300 0.310 0.325 4
E1 0.240
0.250
0.280
3
e
0.100
BSC
eA
0.300 BSC
4
L 0.115
0.130 0.150 2
Top View
Side View
End View
