16
ATF1508ASV(L)
1408F–PLD–10/02
Boundary-scan
Definition Language
(BSDL) Models for
the ATF1508
These are now available in all package types via the Atmel web site. These models can
be used for Boundary-scan Test Operation in the ATF1508ASV(L) and have been
scheduled to conform to the IEEE 1149.1 standard.
BSC Configuration for Macrocell
0
1
D Q
0
1
0
1
D Q D Q
Capture
DR
Capture
DR
Update
DR
0
1
0
1
D Q D Q
TDI
TDI
OUTJ
OEJ
Shift
Shift
Clock
Clock
Mode
TDO
TDO
Pin BSC
Macrocell BSC
Pin
Pin
