11. Revision History
Please note that the following page numbers referred to in this section refer to the specific revision
mentioned, not to this document.
Revision No. History
4986F-AUTO-05/08
•
Section 3.15 “INH Output Pin” on page 6 changed
•
Section 5.5 “Fail-safe Features” on page 13 changed
•
Section 6.1 “Typical Timing Sequence with R
WD_OSC
= 51 k
Ω
” on page 15
changed
•
Section 8 “Electrical Characteristics” numbers 1.6 to 1.8 on page 18
changed
4986E-AUTO-02/08
•
Figure 2-1 on page 3 renamed
•
Figure 6-1 “Timing Sequence with R
WD_OSC
= 51 k
Ω
” on page 16
changed
•
Figure 8-3 “Application Circuit with External NPN” on page 26 added
4986D-AUTO-10/07
•
Section 9 “Ordering Information” on page 26 changed
4986C-AUTO-09/07
•
Features changed
•
Sections 4.2, 4.3, 4.4 and 4.5 changed
•
Figures 4-2, 4-3, 4-4, 5-1, 5-2, 5-3, 5-6, 6-1 and 6-2 changed
•
Section 7 “Absolute Maximum Ratings” changed”
•
Section 8 “Electrical Characteristics”: numbers 17.9 and 18.9 changed
4986B-AUTO-06/07
•
Put datasheet into a new template
•
Part number ATA6626 added
•
Features changed
•
Description text changed
•
Figure 1-1 “Block Diagram” changed
•
Figure 2-1 “Pinning SO8 changed”
•
Figure 4-3 “LIN Wake Up from Silent Mode” changed
•
Figure 4-5 “LIN Wake Up from Sleep Mode” changed
•
Sections 3.2, 3.4, 3.7, 3.8, 3.9, 3.10, 3.11, 3.12, 3.13 and 3.14 changed
•
Sections 4.2, 4.3, 4.4, 4.5, 5.1, 5.2, 5.3, 5.5, 5.6, 6.1 and 6.2 changed
•
Section 8 “Electrical Characteristics”: numbers 1.3, 3.5, 8.4, 12.1, 15.5,
17.9, 18 and 18.9 changed
•
Figure 8-2 “Application Circuit” changed
•
Section 9 “Ordering Information” changed
•
Section 10 “Package Information” changed
