Figure 8-1. Definition of Bus Timing Characteristics
TXD
(Input to transmitting node)
VS
(Transceiver supply
of transmitting node)
RXD
(Output of receiving node1)
RXD
(Output of receiving node2)
LIN Bus Signal
Thresholds of
receiving node1
Thresholds of
receiving node2
t
Bus_rec(max)
t
rx_pdr(1)
t
rx_pdf(2)
t
rx_pdr(2)
t
rx_pdf(1)
t
Bus_dom(min)
t
Bus_dom(max)
TH
Rec(max)
TH
Dom(max)
TH
Rec(min)
TH
Dom(min)
t
Bus_rec(min)
t
Bit
t
Bit
t
Bit
