27
4986F–AUTO–07/08
ATA6622/ATA6624/ATA6626
10. Package Information
9. Ordering Information
Extended Type Number Package Remarks
ATA6622-PGPW QFN20 3.3V LIN system-basis-chip, Pb-free, 1.5k, taped and reeled
ATA6624-PGPW QFN20 5V LIN system-basis-chip, Pb-free, 1.5k, taped and reeled
ATA6622-PGQW QFN20 3.3V LIN system-basis-chip, Pb-free, 6k, taped and reeled
ATA6624-PGQW QFN20 5V LIN system-basis-chip, Pb-free, 6k, taped and reeled
ATA6626-PGQW QFN20 5V LIN system-basis-chip, Pb-free, 6k, taped and reeled
specifications
according to DIN
technical drawings
Issue: 2; 09.02.07
Drawing-No.: 6.543-5129.01-4
0.2
0.9 ±0.1
0.65 nom.
16 20
10 6
11
15
5
1
3.1 ±0.15
Bottom
2.6
20
1
5
5
Top
Pin 1 identification
Package: VQFN_5 x 5_20L
Exposed pad 3.1 x 3.1
Dimensions in mm
Not indicated tolerances ±0.05
0.6
±0.1
0.28 ±0.07
0.05 -0.05
0
