29
AT45DB041B
1938F–DFLSH–10/02
Packaging Information
14C1 – CBGA
2325 Orchard Parkway
San Jose, CA 95131
TITLE DRAWING NO.
R
REV.
14C1, 14-ball (3 x 5 Array), 4.5 x 7 x 1.4 mm Body, 1.0 mm Ball
Pitch Chip-scale Ball Grid Array Package (CBGA)
A 14C1
04/11/01
Dimensions in Millimeters and (Inches).
Controlling dimension: Millimeters.
A
B
C
D
E
3 2 1
4.0 (0.157)
1.25 (0.049) REF
0.46 (0.018)
DIA BALL TYP
2.0 (0.079)
7.10(0.280)
6.90(0.272)
1.40 (0.055) MAX
0.30 (0.012)MIN
4.60(0.181)
4.40(0.173)
1.00 (0.0394) BSC
NON-ACCUMULATIVE
1.50 (0.059) REF
A1 ID
1.00 (0.0394) BSC
NON-ACCUMULATIVE
TOP VIEW
SIDE VIEW
BOTTOM VIEW
