52
AT40K/AT40KLV Series FPGA
0896C–FPGA–04/02
Note: 1. In SBGA packages, Power and Ground pins do not connect directly to die. They connect to Power and Ground planes inside
the package.
Power and Ground Pinouts for 352 SBGA
(1)
VCC Pins
A10 A17 B2 B25 D7 D13 D19
G23 H4 K1 K26 N23 P4 U1
U26 W23 Y4 AC8 AC14 AC20 AE2
AE25 AF10 AF17
GND Pins
A1 A2 A5 A8 A14 A19 A22
A25 A26 B1 B26 E1 E26 H1
H26 N1 P26 W1 W26 AB1 AB26
AE1 AE26 AF1 AF2 AF5 AF8 AF13
AF19 AF22 AF25 AF26
