AC Timing Characteristics – 5V Operation AT40K
Delays are based on fixed loads and are described in the notes.
Maximum times based on worst case: V
CC
= 4.75V, temperature = 70
°C
Minimum times based on best case: V
CC
= 5.25V, temperature = 0
°C
Maximum delays are the average of t
PDLH
and t
PDHL
.
Cell Function
Parameter
Path
-2
Units
Notes
Async RAM
Write
t
WECYC
(Minimum)
cycle time
8.0
ns
Write
t
WEL
(Minimum)
we
3.0
ns
Pulse width low
Write
t
WEH
(Minimum)
we
3.0
ns
Pulse width high
Write
t
AWS
(Minimum)
wr addr setup -> we
2.0
ns
Write
t
AWH
(Minimum)
wr addr hold -> we
0.0
ns
Write
t
DS
(Minimum)
din setup -> we
2.0
ns
Write
t
DH
(Minimum)
din hold -> we
0.0
ns
Write/Read
t
DD
(Maximum)
din -> dout
4.6
ns
rd addr = wr addr
Read
t
AD
(Maximum)
rd addr -> dout
3.1
ns
Read
t
OZX
(Maximum)
oe -> dout
1.6
ns
Read
t
OXZ
(Maximum)
oe -> dout
2.0
ns
Sync RAM
Write
t
CYC
(Minimum)
cycle time
8.0
ns
Write
t
CLKL
(Minimum)
clk
3.0
ns
Pulse width low
Write
t
CLKH
(Minimum)
clk
3.0
ns
Pulse width high
Write
t
WCS
(Minimum)
we setup -> clk
2.0
ns
Write
t
WCH
(Minimum)
we hold -> clk
0.0
ns
Write
t
ACS
(Minimum)
wr addr setup -> clk
2.0
ns
Write
t
ACH
(Minimum)
wr addr hold -> clk
0.0
ns
Write
t
DCS
(Minimum)
wr data setup -> clk
2.0
ns
Write
t
DCH
(Minimum)
wr data hold -> clk
0.0
ns
Write/Read
t
CD
(Maximum)
clk -> dout
3.5
ns
rd addr = wr addr
Read
t
AD
(Maximum)
rd addr -> dout
3.1
ns
Read
t
OZX
(Maximum)
oe -> dout
1.6
ns
Read
t
OXZ
(Maximum)
oe -> dout
2.0
ns
