30
AT45DB021B
1937F–DFLSH–10/02
28R – SOIC
2325 Orchard Parkway
San Jose, CA 95131
TITLE DRAWING NO.
R
REV.
28R, 28-lead, 0.330" Body, Plastic Gull Wing Small Outline (SOIC)
A 28R
04/11/01
Dimensions in Millimeters and (Inches).
Controlling dimension: Inches.
0.508(0.020)
0.356(0.014)
8.79(0.346)
8.59(0.338) 12.50(0.494)
11.70(0.460)
1.27(0.050) BSC
18.50(0.728)
18.00(0.708)
2.79(0.110)
2.39(0.094)
0.305(0.012)
0.203(0.008)
1.27(0.050)
0.94(0.037)
0.014(0.356)
0.002(0.051)
0º ~ 8º
PIN 1
