DS1245Y/AB
041497 11/12
DS1245Y/AB NONVOLATILE SRAM, 34–PIN POWERCAP MODULE WITH POWERCAP
PKG
DIM
INCHES
MIN NOM MAX
A 0.920 0.925 0.930
B 0.955 0.960 0.965
C 0.240 0.245 0.250
D 0.052 0.055 0.058
E 0.048 0.050 0.052
F 0.015 0.020 0.025
G 0.020 0.025 0.030
TOP VIEW
SIDE VIEW
BOTTOM VIEW: REFERENCE ONLY
COMPONENTS AND PLACEMENTS
MAY DIFFER FROM THOSE SHOWN
