11. Revision History
Please note that the following page numbers referred to in this section refer to the specific revision
mentioned, not to this document.
Revision No. History
4957E-AUTO-10/07
•
Section 9 “Ordering Information” on page 20 changed
4957D-AUTO-07/07
•
Features changed
•
Block diagram changed
•
Application diagram changed
•
Text changed under the headings:
3.2, 3.3, 3.4, 3.6, 3.7, 3.8, 3.9, 4, 4.1, 4.2, 4.3, 4.4, 4.5, 5.5, 5.6, 6
•
Figure 4-2, 4-3, 4-4, 4-5, 8-2: changed
•
Figure title 6-1: text changed
•
Abs. Max. Ratings: row “Output current NRES” added
•
El. Char. table: values changed in the following rows:
1.3, 5.1, 5.3, 5.4, 6.9, 6.12, 7.9, 11.1
4957C-AUTO-02/07
•
Features on page 1 changed
•
Table 2-1 “Pin Description” on page 2 changed
•
Section 3-1 “Physical Layer Compatibility” on page 3 added
•
Section 3-2 “Supply Pin (VS) on page 3 changed
•
Section 3-3 “Ground Pin (GND) on page 3 changed
•
Section 3-8 “Dominant Time-out Function (TXD)” on page 4 changed
•
Section 4-1 “Normal Mode” on page 5 changed
•
Section 4-2 “Silent Mode” on page 5 changed
•
Figure 4-3 “LIN Wake-up Waveform Diagram from Silent Mode” on page
6 changed
•
Section 4.3 “Sleep Mode” on page 7 changed
•
Section 4-5 “Unpowered Mode” on page 7 changed
•
Figure 4-4 “Switch to Sleep Mode” on page 8 changed
•
Figure 4-6 “V
CC
Voltage Regulator: Ramp up and Undervoltage” on page
9 changed
•
Section 5 “Fail-safe Features on page 9 changed
•
Section 6 “Voltage Regulator” on page 10 changed
•
Section 7 “Absolute Maximum Ratings” on page 11 changed
•
Section 8 “Electrical Characteristics” on pages 12 to 16 changed
•
Section 9 “Ordering Information” on page 18 changed
