AT27C1024
3
Note:
1. Minimum voltage is -0.6V dc which may undershoot to -2.0V for pulses of less than 20 ns. Maximum output pin voltage is
V
CC
+ 0.75V dc which may overshoot to +7.0V for pulses of less than 20 ns.
Notes:
1. X can be V
IL
or V
IH
.
2. Refer to Programming Characteristics.
3. V
H
= 12.0 ± 0.5V.
4. Two identifier words may be selected. All Ai inputs are held low (V
IL
), except A9 which is set to V
H
and A0 which is toggled
low (V
IL
) to select the Manufacturer’s Identification word and high (V
IH
) to select the Device Code word.
5. Standby V
CC
current (I
SB
) is specified with V
PP
= V
CC
. V
CC
> V
PP
will cause a slight increase in I
SB
.
Absolute Maximum Ratings*
Temperature Under Bias ............................... -55
°
C to + 125
°
C
*NOTICE:
Stresses beyond those listed under “Absolute Maxi-
mum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional
operation of the device at these or any other condi-
tions beyond those indicated in the operational sec-
tions of this specification is not implied. Exposure to
absolute maximum rating conditions for extended
periods may affect device reliability.
Storage Temperature .................................... -65
°
C to + 150
°
C
Voltage on Any Pin with
Respect to Ground ........................................-2.0V to + 7.0V
(1)
Voltage on A9 with
Respect to Ground .....................................-2.0V to + 14.0V
(1)
V
PP
Supply Voltage with
Respect to Ground ......................................-2.0V to + 14.0V
(1)
Operating Modes
Mode/Pin
CE
OE
PGM
Ai
V
PP
Outputs
Read
V
IL
V
IL
X
(1)
Ai
X
D
OUT
Output Disable
X
V
IH
X
X
X
High Z
Standby
V
IH
X
X
X
X
(5)
High Z
Rapid Program
(2)
V
IL
V
IH
V
IL
Ai
V
PP
D
IN
PGM Verify
V
IL
V
IL
V
IH
Ai
V
PP
D
OUT
PGM Inhibit
V
IH
X
X
X
V
PP
High Z
Product Identification
(4)
V
IL
V
IL
X
A9 = V
H
(3)
A0 = V
IH
or V
IL
A1 - A15 = V
IL
V
CC
Identification Code
