12-Channel/8-Channel, Flash-Configurable System
Managers with Nonvolatile Fault Registers
MAX16070/MAX16071
22 _____________________________________________________________________________________
Table 11. Fault Threshold Registers
REGISTER
ADDRESS
FLASH
ADDRESS
BIT RANGE DESCRIPTION
48h 248h [7:0] MON1 secondary threshold
49h 249h [7:0] MON1 overvoltage threshold
4Ah 24Ah [7:0] MON1 undervoltage threshold
4Bh 24Bh [7:0] MON2 secondary threshold
4Ch 24Ch [7:0] MON2 overvoltage threshold
4Dh 24Dh [7:0] MON2 undervoltage threshold
4Eh 24Eh [7:0] MON3 secondary threshold
4Fh 24Fh [7:0] MON3 overvoltage threshold
50h 250h [7:0] MON3 undervoltage threshold
51h 251h [7:0] MON4 secondary threshold
52h 252h [7:0] MON4 overvoltage threshold
53h 253h [7:0] MON4 undervoltage threshold
54h 254h [7:0] MON5 secondary threshold
55h 255h [7:0] MON5 overvoltage threshold
56h 256h [7:0] MON5 undervoltage threshold
57h 257h [7:0] MON6 secondary threshold
58h 258h [7:0] MON6 overvoltage threshold
59h 259h [7:0] MON6 undervoltage threshold
5Ah 25Ah [7:0] MON7 secondary threshold
5Bh 25Bh [7:0] MON7 overvoltage threshold
5Ch 25Ch [7:0] MON7 undervoltage threshold
5Dh 25Dh [7:0] MON8 secondary threshold
5Eh 25Eh [7:0] MON8 overvoltage threshold
5Fh 25Fh [7:0] MON8 undervoltage threshold
60h 260h [7:0] MON9 secondary threshold
61h 261h [7:0] MON9 overvoltage threshold
62h 262h [7:0] MON9 undervoltage threshold
63h 263h [7:0] MON10 secondary threshold
64h 264h [7:0] MON10 overvoltage threshold
65h 265h [7:0] MON10 undervoltage threshold
66h 266h [7:0] MON11 secondary threshold
67h 267h [7:0] MON11 overvoltage threshold
68h 268h [7:0] MON11 undervoltage threshold
69h 269h [7:0] MON12 secondary threshold
6Ah 26Ah [7:0] MON12 overvoltage threshold
6Bh 26Bh [7:0] MON12 undervoltage threshold
6Ch 26Ch [7:0] Secondary overcurrent threshold
