______________________________________________________________________________________ 37
MAX16068
6-Channel, Flash-Configurable System Manager
with Nonvolatile Fault Registers
Register Map
FLASH
ADDRESS
REGISTER
ADDRESS
READ/
WRITE
DESCRIPTION
ADC VALUES, FAULT REGISTERS, GPIO_s AS INPUT PORTS—NOT IN FLASH
— 000 R MON1 ADC output, MSBs
— 001 R MON1 ADC output, LSBs
— 002 R MON2 ADC output, MSBs
— 003 R MON2 ADC output, LSBs
— 004 R MON3 ADC output, MSBs
— 005 R MON3 ADC output, LSBs
— 006 R MON4 ADC output, MSBs
— 007 R MON4 ADC output, LSBs
— 008 R MON5 ADC output, MSBs
— 009 R MON5 ADC output, LSBs
— 00A R MON6 ADC output, MSBs
— 00B R MON6 ADC output, LSBs
— 00C–01A — Reserved
— 01B R/W Fault register—failed line flags
— 01C R/W Fault register—failed line flags
— 01D — Reserved
— 01E R GPIO_ data in (read only)
— 01F — Reserved
— 020 R/W Flash status/reset output monitor
— 021 — Reserved
GPIO_ AND OUTPUT DEPENDENCIES/CONFIGURATIONS
230 030 — Reserved
231 031 — Reserved
232 032 — Reserved
233 033 — Reserved
234 034 — Reserved
235 035 — Reserved
236 036 R/W FAULT dependencies
237 037 R/W FAULT dependencies
238–23A 038–03A — Reserved
23B 03B R/W RESET output configuration
23C 03C R/W RESET output dependencies
23D 03D R/W RESET output dependencies
23E 03E R/W GPIO data out
23F 03F R/W GPIO configuration
240 040 R/W GPIO configuration, ARANEN (ARA Enable)
241–242 041–042 — Reserved
