Preliminary W24L11
- 4 -
AC Characteristics, continued
(V
DD
= 3.0V to 3.6 V; V
SS
= 0V; T
A
(
°
C) = 0 to 70)
Read Cycle
PARAMETER
SYMBOL
W24L11-70L/LL
UNIT
MIN.
MAX.
Read Cycle Time
T
RC
70
-
nS
Address Access Time
T
AA
-
70
nS
Chip Select Access Time
T
ACS
-
70
nS
Output Enable to Output Valid
T
AOE
-
35
nS
Chip Selection to Output in Low Z
T
CLZ
*
10
-
nS
Output Enable to Output in Low Z
T
OLZ
*
5
-
nS
Chip Deselection to Output in High Z
T
CHZ
*
-
30
nS
Output Disable to Output in High Z
T
OHZ
*
-
30
nS
Output Hold from Address Change
T
OH
10
-
nS
∗
These parameters are sampled but not 100% tested
Write Cycle
PARAMETER
SYMBOL
W24L11-70L/LL
UNIT
MIN.
MAX.
Write Cycle Time
T
WC
70
-
nS
Chip Selection to End of Write
T
CW
55
-
nS
Address Valid to End of Write
T
AW
55
-
nS
Address Setup Time
T
AS
0
-
nS
Write Pulse Width
T
WP
50
-
nS
Write Recovery Time
CS1
, CS2, WE
T
WR
0
-
nS
Data Valid to End of Write
T
DW
45
-
nS
Data Hold from End of Write
T
DH
0
-
nS
Write to Output in High Z
T
WHZ
*
-
25
nS
Output Disable to Output in High Z
T
OHZ
*
-
25
nS
Output Active from End of Write
T
OW
5
-
nS
∗
These parameters are sampled but not 100% tested
