MAX7042
308MHz/315MHz/418MHz/433.92MHz
Low-Power, FSK Superheterodyne Receiver
16 ______________________________________________________________________________________
Chip Information
PROCESS: CMOS
Table 3. Component Values for Typical Application Circuit
COMPONENT
VALUE FOR
315MHz RF
VALUE FOR
433.92MHz RF
DESCRIPTION
C1 0.01µF 0.01µF 5%
C2 220pF 220pF 5%
C3 220pF 220pF 5%
C4 470pF 470pF 5%
C5 0.047µF 0.047µF 10%
C6 0.1µF 0.1µF 10%
C7 100pF 100pF 10%
C8 100pF 100pF 10%
C9 1.2pF Open ±0.1pF
C10 220pF 220pF 10%
C11 100pF 100pF 10%
C12 1500pF 1500pF 10%
C13 220pF 220pF 10%
C14 100pF 100pF 10%
C15 100pF 100pF 10%
C16 0.1µF 0.1µF 10%
L1 82nH 39nH Coilcraft 0603CS
L2 30nH 16nH Murata LQW18A
L3 3.9nH Short Coilcraft 0603CS
R1 100k Ω 100k Ω 5%
Y1 9.50939MHz 13.22563MHz Crystal
Y2 10.7MHz ceramic filter 10.7MHz ceramic filter Murata SFECV10.7 series
