MAX7393/MAX7394
Precision Silicon Oscillators with
Enable or Autoenable
_______________________________________________________________________________________
3
Note 1: All parameters are production tested at T
A
= +25°C. Specifications over temperature are guaranteed by design and
characterization.
Note 2: The total supply current is the sum of I
CC
and I
CC2
.
Note 3: Guaranteed by design and characterization. Not production tested.
Note 4: Output frequency is production tested at T
A
= +25°C and T
A
= +85°C.
Note 5: Output frequency is production tested at T
A
= +25°C.
ELECTRICAL CHARACTERISTICS (continued)
(V
CC
= V
CC2
= +2.4V to +3.6V, C
L
= 10pF, T
A
= -40°C to +125°C, unless otherwise noted. Typical values are at V
CC
= V
CC2
= +3.3V,
T
A
= +25°C, unless otherwise noted.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
FREQUENCY ACCURACY
T
A
= 0°C to +70°C
±20
Clock Frequency Coefficient of
Temperature
V
C C
= V
C C 2
= 3.3V
T
A
= -40°C to +125°C
±50
ppm/°C
Clock Frequency Coefficient of
Supply Voltage
T
A
= +25°C
0.1
0.15
%/V
TD FN
( N ote 4)
±0.25
T
A
= 0°C to
+ 85°C ,
V
C C
= ± 10% µD FN
( N ote 5)
±1.3
TD FN
( N ote 4)
±1.0
Total Accuracy
V
C C
= V
C C 2
= 3.3V
T
A
= - 40°C
to + 125° C ,
V
C C
= ± 10% µD FN
( N ote 5)
±1.8
%
