MAX13173E ELECTRICAL CHARACTERISTICS (continued)
(V CC = +3.135V to +5.5V, V L = +1.62V to +5.5V, C1 = C2 = 1µF, C3 = C4 = C5 = 4.7µF, Figure 15, T A = -40°C to +85°C, unless
otherwise noted. Typical values are at V CC = +3.3V, V L = +1.8V, T A = +25°C.) (Note 2)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Output Slew Rate SR R/F
R L = 3kΩ, C L = 2500pF (swing in ±3V)
Figures 4, 10
4 30 V/µs
Transmitter Input to Output Delay t PHL , t PLH R L = 3kΩ, C L = 2500pF, Figures 4, 10 1 2 µs
V.28 RECEIVER (All CHANNELS)
Input Threshold Low V IL 0.8 1.2 V
Input Threshold High V IH 1.2 2 V
Input Hysteresis V HYST 0.25 V
Input Resistance R IN -15V ≤ V IN ≤ +15V 3 5 7 kΩ
Rise or Fall Time t r , t f Figures 5, 11 3 ns
Receiver Input to Output Delay t PHL, t PLH Figures 5, 11 150 ns
ESD PROTECTION
Human Body Model ±15
Air Gap Discharge IEC 61000-4-2 ±15 T_OUT, T_OUT/R_IN_, R_IN
Contact Discharge ±5
kV
MAX13175E ELECTRICAL CHARACTERISTICS (continued)
(V
CC
= +3.135V to +5.5V, V
L
= +1.62V to +5.5V, C1 = C2 = 1µF, C3 = C4 = C5 = 4.7µF, Figure 15, T
A
= -40°C to +85°C, unless
otherwise noted. Typical values are at V CC = +3.3V, V L = +1.8V, T A = +25°C.) (Note 2)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
V CC Operating Range V CC 3.135 5.5 V
V L Operating Range V L 1.62 V CC V
V DD Operating Range V DD 4.5 7.1 V
V EE Operating Range V EE -7.1 -4 V
V L POR Rising Threshold 0.7 1.06 1.46 V
V CC POR Rising Threshold 1 1.88 2.75 V
V DD Supply Current I DD
All inputs connected to GND or V L , except
no-cable mode
0.05 0.25 mA
I CC
All inputs connected to GND or V L , except
no-cable mode
2.15 5.9 mA
V CC Supply Current
I CC_NOCAB V EE = 0V, M[x] = 1111 (Note 5) 1.29 2.6 mA
V
L
Supply Current I
L
All inputs connected to GND or V
L
-1 +1 µA
V EE Supply Current I EE All inputs connected to GND or V L -3.5 -1 mA
TERMINATOR INPUTS
Differential-Mode Impedance
V.35 Mode
-2V ≤ V CM ≤ +2V, all channels, Figure 12 90 104 110 Ω
Common-Mode Impedance V.35
Mode
-2V ≤ V CM ≤ +2V, all channels, Figure 13 135 153 165 Ω
