MAX13171E/MAX13173E/MAX13175E
Multiprotocol, Pin-Selectable
Data Interface Chipset
4
_______________________________________________________________________________________
MAX13171E ELECTRICAL CHARACTERISTICS (continued)
(V
CC
= +3.135V to +5.5V, V
L
= +1.62V to +5.5V, C1 = C2 = 1µF, C3 = C4 = C5 = 4.7µF (Figure 15), T
A
= -40°C to +85°C, unless oth-
erwise noted. Typical values are at V
CC
= +3.3V, V
L
= +1.8V, T
A
= +25°C.) (Note 2)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Figures 2, 6
22
28
Transmitter Input to Output
Propagation Delay (Figures 2, 6)
t
PHL
, t
PLH
V
L
≥ +3V, Figures 2, 6
20
25
ns
Data Skew
|t
PHL
-t
PLH
|
Figures 2, 6 (Note 3)
2
ns
Channel-to-Channel Skew
t
SKEW
Figures 2, 6 (Notes 3, 4)
3
ns
V.11 RECEIVER
Differential Threshold Voltage
V
TH
-7V ≤ V
CM
≤ +7V
-200
-50
mV
Input Hysteresis
∆V
TH
-7V ≤ V
CM
≤ +7V
15
mV
Receiver Input Current
I
IN
-10V ≤ V
A,B
≤ +10V
-0.66
+0.66
mA
Receiver Input Resistance
R
IN
-10V ≤ V
A,B
≤ +10V
15
30
kΩ
Rise or Fall Time
t
r
, t
f
Figures 2, 7
3
ns
Receiver Input to Output Delay
t
PHL
, t
PLH
Figures 2, 7
2.5
ns
Data Skew
|t
PHL
-t
PLH
|
Figures 2, 7 (Note 3)
3
ns
Channel-to-Channel Skew
t
SKEWR
Figures 2, 7 (Notes 3, 4)
3
ns
V.35 TRANSMITTER
Differential Output Voltage
V
OD
Full load, -4V < V
CM
< +4V, Figure 3
±0.44
±0.55
±0.66
V
Output High Current
I
OH
V
A,B
= 0V
-13
-11
-9
mA
Output Low Current
I
OL
V
A,B
= 0V
9
11
13
mA
Output Leakage Current
I
Z
-0.25V ≤ V
OUT
≤ +0.25V, power off or
no-cable mode
±0.05
±5
µA
Rise or Fall Time
t
r
, t
f
Figures 3, 6
5
ns
Transmitter Input to Output Delay
t
PLH,
t
PHL
Figures 3, 6
19
35
ns
Data Skew
|t
PLH -
t
PHL
|
Figures 3, 6 (Note 3)
3
ns
Channel-to-Channel Skew
t
SKEWR
Figures 3, 6 (Notes 3, 4)
3
ns
V.35 RECEIVER
Differential Threshold Voltage
V
TH
-2V ≤ V
CM
≤ +2V
-200
-50
mV
Input Hysteresis
∆V
TH
-2V ≤ V
CM
≤ +2V
15
mV
Receiver Input Current
I
IN
-10V ≤ V
A,B
≤ +10V
-0.66
+0.66
mA
Receiver Input Resistance
R
IN
-10V ≤ V
A,B
≤ +10V
15
30
kΩ
Rise or Fall Time
t
r
, t
f
Figures 3, 7
3
ns
Receiver Input to Output Delay
t
PHL
, t
PLH
Figures 3, 7
25
ns
Data Skew
|t
PHL
- t
PLH
|
Figures 3, 7 (Note 3)
3
ns
Channel-to-Channel Skew
t
SKEWR
Figures 3, 7 (Notes 3, 4)
3
ns
V.28 TRANSMITTER
Open circuit
7.1
Output-Voltage Swing
|V
OD
|
R
L
= 3kΩ
5
6
V
Short-Circuit Current
I
OH
85
mA
