Functional diagram – Rainbow Electronics MAX7358 User Manual
Page 9
MAX7356/MAX7357/MAX7358
1-to-8 I
2
C Bus Switches/Multiplexers with Bus
Lock-Up Detection, Isolation, and Notification
_______________________________________________________________________________________
9
SC0
SC1
SC2
SC3
SC6
SC7
SD0
SD1
SD2
SD3
SD6
SD7
V
DD
SCL
SDA
SWITCH ENABLE/DISABLE
LOCK-UP DETECTION
AND WIGGLE TEST
POWER-ON
RESET
GLITCH FILTER
INT LOGIC
I
2
C BUS
CONTROL
REGISTER BANK WITH SWITCH CONTROL LOGIC
A0
GND
( ) ONLY FOR THE MAX7357 AND MAX7358
A1
A2
RST (RST/INT)
Functional Diagram
