MAX17000

Complete DDR2 and DDR3 Memory
Power-Management Solution

4

_______________________________________________________________________________________

ELECTRICAL CHARACTERISTICS (continued)

(V

IN

= 12V, V

CC

= V

DD

= V

SHDN

= V

REFIN

= 5V, V

CSL

= 1.8V, STDBY = SKIP = AGND, T

A

= 0°C to +85°C, unless otherwise noted.

Typical values are at T

A

= +25°C.) (Note 1)

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

REFERENCE BUFFER (VTTR)

I

VTT

= ±1mA

-10

+10

VTTR Output Accuracy (Adj)

REFIN to VTTR

I

VTT

= ±3mA

-20

+20

I

VTT

= ±1mA

-10

+10

VTTR Output Accuracy (Preset)

V

CSL

/2 to VTTR

I

VTT

= ±3mA

-20

+20

mV

VTTR Maximum
Recommended Current

Source/sink

5 mA

FAULT DETECTION (SMPS)

SMPS OVP and PGOOD1
Upper Trip Threshold

12 15 18 %

SMPS OVP and PGOOD1
Upper Trip Threshold
Fault-Propagation Delay

t

OVP

FB forced 25mV above trip threshold

10

μs

SMPS Output Undervoltage
Fault-Propagation Delay

t

UVP

200 μs

SMPS PGOOD1 Lower Trip
Threshold

Measured at FB, hysteresis = 25mV

-12

-15

-18

%

PGOOD1 Lower Trip Threshold
Propagation Delay

t

PGOOD1

FB forced 50mV below PGOOD1 trip
threshold

10 μs

PGOOD1 Output Low Voltage

I

SINK

= 3mA

0.4

V

PGOOD1 Leakage Current

I

PGOOD1

FB = 1V (PGOOD1 high impedance),
PGOOD1 forced to 5V, T

A

= +25°C

1 μA

TON POR Threshold

V

POR(IN)

Rising edge, PWM disabled below this level;
hysteresis = 200mV

3.0

V

FAULT DETECTION (VTT)
PGOOD2 Upper Trip Threshold

Hysteresis = 25mV

8

10

13

%

PGOOD2 Lower Trip Threshold

Hysteresis = 25mV

-13

-10

-8

%

PGOOD2 Propagation Delay

t

PGOOD2

VTTS forced 50mV beyond PGOOD2
trip threshold

10 μs

PGOOD2 Fault Latch Delay

VTTS forced 50mV beyond PGOOD2
trip threshold

5 ms

PGOOD2 Output Low Voltage

I

SINK

= 3mA

0.4

V

PGOOD2 Leakage Current

I

PGOOD2

VTTS = V

REFIN

(PGOOD2 high impedance),

PGOOD2 forced to 5V, T

A

= +25°C

1 μA

FAULT DETECTION
Thermal-Shutdown Threshold

T

SHDN

Hysteresis = 15

°C

160

°C

V

CC

Undervoltage Lockout

Threshold

V

UVLO(VCC)

Rising edge, IC disabled below this level
hysteresis = 200mV

3.8 4.1 4.4 V

CSL Discharge MOSFET

OVP = V

CC

16
