MAX17000
Standard Application Circuits
The MAX17000 standard application circuit (Figure 1)
generates the VDDQ, VTT, and VTTR rails for DDR,
DDR2, or DDR3 in a notebook computer. See Table 1 for
component selections. Table 2 lists the component man-
ufacturers. Table 3 is the operating mode truth table.
Complete DDR2 and DDR3 Memory
Power-Management Solution
14
______________________________________________________________________________________
V
OUT
= 1.5V TO 1.8V AT 10A
V
OUT
= 1.5V TO 1.8V AT 6A
COMPONENT
V
IN
= 7V TO 20V (300kHz)
V
IN
= 7V TO 16V (500kHz)
Input Capacitor
(2x) 10μF, 25V
Taiyo Yuden TMK432BJ106KM
10μF, 25V
Taiyo Yuden TMK432BJ106KM
Output Capacitor
(2x) 330μF, 2.5V ,12m
Ω (C2 case)
SANYO 2R5TPE330MCC2
(2x) 220μF, 2.5V, 21m
Ω (B2 case)
SANYO 2R5TPE220MLB
Inductor
1.4μH, 12A, 3.4m
Ω (typ)
Sumida CDEP105(L)NP-1R4
1.4μH, 12A, 3.4m
Ω (typ)
Sumida CDEP105(L)NP-1R4
Current-Sensing Resistor
2m
Ω, 0.5W (2010)
Vishay WSL20102L000FEA
3m
Ω, 0.5W (2010)
Vishay WSL20103L000FEA
MOSFETs
30V, 20A n-channel MOSFET (high side)
Fairchild FDMS8690;
30V, 40A n-channel MOSFET (low side)
Fairchild FDMS8660S
30V 20A n-channel MOSFET (high side)
Fairchild FDMS8690;
30V 40A n-channel MOSFET (low side)
Fairchild FDMS8660S
Table 1. Component Selection for Standard Applications
SUPPLIER
PHONE
WEBSITE
INDUCTORS
Dale (Vishay)
402-563-6866 (USA)
www.vishay,com
NEC/TOKIN America, Inc.
510-324-4110 (USA)
www.nec-tokinamerica.com
Panasonic Corp.
65-231-3226 (Singapore), 408-749-9714 (USA)
www.panasonic.com
Sumida Corp.
408-982-9660 (USA)
www.sumida.com
TOKO America, Inc.
858-675-8013 (USA)
www.tokoam.com
CAPACITORS
AVX Corp.
843-448-9411 (USA)
www.avxcorp.com
KEMET Corp.
408-986-0424 (USA)
www.kemet.com
Panasonic Corp.
65-231-3226 (Singapore), 408-749-9714 (USA)
www.panasonic.com
SANYO Electric Co., Ltd.
81-72-870-6310 (Japan), 619-661-6835 (USA)
www.sanyodevice.com
Taiyo Yuden
03-3667-3408 (Japan), 408-573-4150 (USA)
www.t-yuden.com
TDK Corp.
847-803-6100 (USA), 81-3-5201-7241 (Japan)
www.component.tdk.com
SENSING RESISTORS
Vishay
402-563-6866 (USA)
www.vishay,com
MOSFET
Fairchild Semiconductor
800-341-0392 (USA)
www.fairchildsemi.com
DIODES
Central Semiconductor Corp.
631-435-1110
www.centralsemi.com
Nihon Inter Electronics Corp.
81-3-3343-84-3411 (Japan)
www.niec.co.jp
Table 2. Component Suppliers
