W29EE512
Publication Release Date: April 2000
- 9 - Revision A6
DC CHARACTERISTICS
Absolute Maximum Ratings
PARAMETER RATING UNIT
Power Supply Voltage to V ss Potential -0.5 to +7.0 V
Operating Temperature 0 to +70
°
C
Storage Temperature -65 to +150
°
C
D.C. Voltage on Any Pin to Ground Potential except A9 -0.5 to V CC +1.0 V
Transient Voltage (¡ Õ 20 nS ) on Any Pin to Ground Potential -1.0 to V CC +1.0 V
Voltage on A9 and OE Pin to Ground Potential
-0.5 to 12.5 V
Note: Exposure to conditions beyond those listed under Absolute Maximum Ratings may adversely affect the life and reliability of the
device.
Operating Characteristics
(V CC = 5.0V ± 10 % , V SS = 0V, T A = 0 to 70 ° C)
PARAMETER SYM. TEST CONDITIONS LIMITS UNIT
MIN. TYP. MAX.
Power Supply
Current I CC CE = OE = V
IL , WE = V IH , all I/Os open
Address inputs = V IL /V IH , at f = 5 MHz
- - 50 mA
Standby Vcc
Current (TTL Input)
I SB 1
CE = V
IH , all I/Os open
Other inputs = V IL /V IH
- 2 3 mA
Standby Vcc
Current (CMOS
Input) I SB 2 CE = V
CC -0.3V, all I/Os open
Other inputs = V CC -0.3V/GND
- 20 100
µ
A
Input Leakage
Current I LI V IN = GND to V CC - - 10
µ
A
Output Leakage
Current I LO V IN = GND to V CC - - 10
µ
A
Input Low Voltage V IL - - - 0.8 V
Input High Voltage V IH - 2.0 - - V
Output Low Voltage V OL I OL = 2.1 mA - - 0.45 V
Output High Voltage V OH1 I OH = -0.4 mA 2.4 - - V
Output High Voltage
CMOS V OH2 I OH = -100
µ
A; V CC = 4.5V 4.2 - - V
