4 Need help? Call 800-620-2790
RF-TVML70 TV Wall Mount
Package contents: hardware
Make sure that you have all the hardware necessary to assemble your new TV wall mount:
Label Hardware Qty.
M-A 4
M-B 4
M-C 4
M-D 4
M-E 4
M-F 4
M-G 4
M-H 4
M-I 4
M-J 4
M-K 4
M-L 4
M-M 4
M-N 4
M4 × 15 mm screw
M4 × 30 mm
screw
M5 × 15 mm screw
M5 × 30 mm
screw
M6 × 15 mm screw
M6 × 30 mm
screw
M8 × 15 mm
screw
M8 × 30 mm
screw
M6/M8 5 mm spacer
M6/M8 10 mm
spacer
M4/M5 Washer
M6/M8 Washer
Pan head screw
M8 x 15 mm
M8 Nylock nut
Label Hardware Qty.
P-A 16
P-B 1
P-C 2
W-A 4
W-B 4
W-C 2
E 1
F 2
G 4
H 2
Button head screw
4 mm Allen wrench
Knob screw M4 x0.7”
5/16" × 2 3/4" (8 mm x 80 mm)
lag bolt
Wall anchor
1/4-20 x 1-1/2”
Hex Socket Screw
Cable tubing
Snap toggle
Cable tie
Cable clip
10 20 30 40 50 60 70 80 90 100mm
1 2 3 4in
