RF-TVML70 TV Wall Mount

STEP 7 - Attach the horizontal rails to the lift assembly

1

Using the 4 mm Allen wrench (P-B), install the right and left horizontal rails (C) onto the lift assembly (A)

using four button head screws (P-A) for each horizontal rail.

You’ll need

C Horizontal rails (4)

P-B 4 mm Allen wrench

P-A Button head
screw (16)
