1. Parts List
PNEG-1649 Top Dry
47
4230 Fan Control Parts List
4240 Fan Control Parts List
Ref #
Part #
Description
Qty
EBTF-
4230-2
EBTF-
4230-3
EBTF-
4230-4
EBTF-
4230-5
EBTF-
4015-6
1
D03-0486 Overload Relay, IEC 97A CLS20 RT22L
1
1
D03-0485 Overload Relay, IEC 64-82A RT22J CLS20
1
1
D03-0482 Overload Relay, IEC 30-43A RT22E CLS20
1
1
D03-0481 Overload Relay, IEC 32A CLS20 RT22D
1
1
D03-0483 Overload Relay, IEC 42-55A RT22G CLS20 03/30/01
1
2
D03-0498 Relay, IEC 3 Pole 96A CL10 #CL10A311MJ
1
2
D03-0497 Relay, IEC 3 Pole 80A CL09 #CL09A311MJ
1
2
D03-0494 Relay, IEC 3 Pole 48A CL06 #CL06A311MJ
1
1
2
D03-0495 Relay, IEC 3 Pole 62A CL07 CL07A311MJ
1
3
FH-3807
Transformer, 1/2 KVA 240/480 110V
1
1
1
3
HF-7566
Transformer, 380>575/120-240 0.5 380-460-575V/120-240V 500VA GE#
1
1
4
D03-0559 Fuse Block, Entrelec Entrelec # 199.095.13
1
1
1
1
1
5
FH-1059
Fuse, 5A
1
1
1
1
1
6
D03-0562 Cover, Fuse Block Bussman Sami-7N
2
2
2
2
2
7
D36-0003 Fuse, Block Panel Mount 1 Fuse
2
2
2
2
2
8
D36-0002 Fuse, #FNQ5 500V Slow-Blow Buss #FNQ5 5 Amp Slow-Blow Fuse
2
2
2
2
2
9
HH-1093
Transformer, 2 Pole Ignition
1
1
1
11
D01-0531 Terminal, Block Entrelec 4 mm 22-10 AWG
33
33
33
33
33
Ref #
Part #
Description
Qty
EBTF-
4240-3
EBTF-
4240-4
EBTF-
4230-5
EBTF-
4015-6
1
056-2276-6
Overload Relay, 90-150A ADJ IEC
1
1
D03-0483
Overload Relay, IEC 42-55A RT22G CLS20 03/30/01
1
1
D03-0482
Overload Relay, IEC 30-43A RT22E CLS20
1
1
D03-0484
Overload Relay, IEC 65A CLS20 RT22H
1
2
D03-0495
Relay, IEC 3 Pole 62A CL07 CL07A311MJ
1
2
D03-0496
Relay, IEC 3 Pole 68A CL08 #CL08A311MJ
1
N/S
056-2072-9
Lug, for 150A Contactor
1
3
FH-3807
Transformer, 1/2 KVA 240/480 110V
1
1
3
HF-7566
Transformer, 380>575/120-240 0.5 380-460-575V/120-240V 500VA GE#
1
1
4
D03-0559
Fuse Block, Entrelec Entrelec # 199.095.13
1
1
1
1
5
FH-1059
Fuse, 5A
1
1
1
1
6
D03-0562
Cover, Fuse Block Bussman Sami-7N
2
2
2
2
7
D36-0003
Fuse, Block Panel Mount 1 Fuse
2
2
2
2
8
D36-0002
Fuse, #FNQ5 500V Slow-Blow Buss #FNQ5 5 Amp Slow-Blow Fuse
2
2
2
2
9
HH-1093
Transformer, 2 Pole Ignition
1
1
1
11
D01-0531
Terminal, Block Entrelec 4 mm 22-10 AWG
33
33
33
33
12
056-2275-8
Coil, Contactor 150A 110V IEC Vendor: SQD #LC1-D15000F7
1
13
056-1951-5
Relay, Aux 1 N.O. 1 N.C. IEC Side
1
