1. Parts List
18 PNEG-1649 Top Dry
Actuator Bottom Pulley Assembly
Actuator Bottom Pulley Assembly Parts List
Ref # Part # Description Qty
1 TAF-6040 Left Hand Pulley Bracket 1
2 TAF-6041 Right Hand Pulley Bracket 1
3 S-7501 1/2" Shoulder Bolt with 3/8" Thread 2
4 TD-100021 Pulley, 2-1/2" x 0.874" Bore Rope 2
5 TF-1298 Bushing, Bronze 1/2" I.D. x 7/8" O.D. 2
6 S-7409 Flat Washer 3/8" SAE ZN Grade 2 2
7 S-4663 Stover Nut 3/8"-16 ZN Grade 2 2
8 TAF-6042 Cable Bracket 1
9 TD-100302 5/16" Jaw Type Forged Steel Swivel 1
10 S-6606 Flange Bolt 5/16"-18 x 3/4" ZN Grade 5 4
11 S-3611 Flange Nut 5/16"-18 YDP Grade 2 4
