1. Parts List
PNEG-1649 Top Dry 15
Actuator Guide Roller and Pulley
Actuator Guide Roller and Pulley Parts List
Ref # Part # Description Qty
1 TF-1431 3/8"-16 x 3-3/4" HHCS Grade 2 1
2 S-7501 1/2" Shoulder Bolt with 3/8" Thread 1
3 S-6999 Bearing Rack and Pinion Sealed 2
4 TAF-6064 Actuator Rod End Top 1
5 TF-1298 Bushing, Bronze 1/2" I.D. x 7/8" O.D. 1
6 TD-100021 Pulley, 2-1/2" x 0.874" Bore Rope 1
7 TAF-6065 Actuator Rod End Bottom 1
8 S-7409 Flat Washer 3/8" SAE ZN Grade 2 1
9 S-4663 Stover Nut 3/8"-16 ZN Grade 2 2
