1. Parts List
PNEG-1649 Top Dry
45
36" Fan Control Parts List
40" Fan Control Parts List
Ref
#
Part #
Description
Qty
EBTF-
3615-1
EBTF-
3615-
3
EBTF-
3615-
4
EBTF-
3615-
5
EBTF-
3615-
6
1
D03-0485
Overload Relay, IEC 64-82A RT22J CLS20
1
1
D03-0482
Overload Relay, IEC 30-43A RT22E CLS20
1
1
D03-0477
Overload Relay, IEC 22A CLS20 RT12T Range
17.5-22.0 Amps Repl.
1
1
D03-0476
Overload Relay, IEC 18A CLS20 RT12S
1
1
D03-0479
Overload Relay, IEC 32A CLS20 RT12V
1
2
D03-0497
Relay, IEC 3 Pole 80A CL09 #CL09A311MJ
1
2
D03-0494
Relay, IEC 3 Pole 48A CL06 #CL06A311MJ
1
2
D03-0491
Relay, IEC 3 Pole 22A CL25 #CL25A310TJ
1
2
D03-0492
Relay, IEC 3 Pole 32A CL04 #CL04A310MJ
1
1
3
FH-3807
Transformer, 1/2 KVA 240/480 110V
1
1
1
3
HF-7566
Transformer, 380>575/120-240 0.5 380-460-575V/
120-240V 500VA GE#
1
1
4
D03-0559
Fuse Block, Entrelec Entrelec # 199.095.13
1
1
1
1
1
5
FH-1059
Fuse, 5A
1
1
1
1
1
6
D03-0562
Cover, Fuse Block Bussman Sami-7N
2
2
2
2
2
7
D36-0003
Fuse, Block Panel Mount 1 Fuse
2
2
2
2
2
8
D36-0002
Fuse, #FNQ5 500V Slow-Blow Buss #FNQ5 5 Amp
Slow-Blow Fuse
2
2
2
2
2
9
HH-1093
Transformer, 2 Pole Ignition
1
1
1
10
TF-1914
Switch, Start for C-7815 15 HP B Baldor Part, GE Brand,
GE# CR453CB2
1
11
D01-0531
Terminal, Block Entrelec 4 mm 22-10 AWG
33
33
33
33
33
Ref #
Part #
Description
Qty
EBTF-
4015-1
EBTF-
4015-3
EBTF-
4015-4
EBTF-
4015-5
EBTF-
4015-6
1
D03-0485
Overload Relay, IEC 64-82A RT22J CLS20
1
1
D03-0482
Overload Relay, IEC 30-43A RT22E CLS20
1
1
D03-0477
Overload Relay, IEC 22A CLS20 RT12T Range
17.5-22.0 Amps Repl.
1
1
D03-0476
Overload Relay, IEC 18A CLS20 RT12S
1
1
D03-0479
Overload Relay, IEC 32A CLS20 RT12V
1
2
D03-0497
Relay, IEC 3 Pole 80A CL09 #CL09A311MJ
1
2
D03-0494
Relay, IEC 3 Pole 48A CL06 #CL06A311MJ
1
2
D03-0491
Relay, IEC 3 Pole 22A CL25 #CL25A310TJ
1
2
D03-0492
Relay, IEC 3 Pole 32A CL04 #CL04A310MJ
1
1
3
FH-3807
Transformer, 1/2 KVA 240/480 110V
1
1
1
3
HF-7566
Transformer, 380>575/120-240 0.5 380-460-575V/
120-240V 500VA GE#
1
1
4
D03-0559
Fuse Block, Entrelec Entrelec # 199.095.13
1
1
1
1
1
5
FH-1059
Fuse, 5A
1
1
1
1
1
6
D03-0562
Cover, Fuse Block Bussman Sami-7N
2
2
2
2
2
7
D36-0003
Fuse, Block Panel Mount 1 Fuse
2
2
2
2
2
8
D36-0002
Fuse, #FNQ5 500V Slow-Blow Buss #FNQ5 5 Amp
Slow-Blow Fuse
2
2
2
2
2
9
HH-1093
Transformer, 2 Pole Ignition
1
1
1
10
TF-1914
Switch, Start for C-7815 15 HP B Baldor Part, GE Brand,
GE# CR453CB2
1
11
D01-0531
Terminal, Block Entrelec 4 mm 22-10 AWG
33
33
33
33
33
