Rough Country 7503 User Manual
Page 4
15. Install the new lifted passenger side spindle on the upper and lower ball joints using the stock castle nuts. Torque to
factory specs. See Photo 13 & 14.
16. Install the new cotter pins provided.
17. Install the tie rod using the castle nut and torque to factory specs. See Photo 15 & 16.
18. Install the cotter pin provided.
19. If your vehicle has ABS install the sensor at this time on the new spindle.
20. Using High Temp grease apply a light coating on the new spindle. Inspect your wheel bearings. If they are worn or
discolored replace them at this time.
21. Slide the rotor with bearings on the spindle shaft. See Photo 17.
22. Install the spindle nut washer and nut. Tighten to factory specs. Do not over tighten.
23. Install the cotter pin provided. Using a hammer lightly tap the stock dust cap into place. See Photo 18.
PHOTO 13
PHOTO 14
PHOTO 15
PHOTO 16
PHOTO 17
PHOTO 18
