1. Jack up the front of the truck and support the frame rails with jack stands. The tool list is on the back page. NEVER
WORK UNDER ANUNSUPPORTED VEHICLE.
2. Starting on the passenger side of the truck remove the front tire.
3. Remove the brake calipers from the spindle bracket using a 13 mm wrench as shown in Photo 1. Zip tie the caliper
to the frame rail. Do not let the caliper hang from the hose. Remove the two bolts securing the bracket from the
spindle using an 18mm socket. See Photo 2. Retain hardware for reuse.
4. Remove the dust cap from the brake rotor using a flat head screwdriver. You will be reusing the dust cap later so do
not puncture it. See Photo 3.
5. Using pliers remove the cotter key from the spindle shaft. See Photo 4. Using a 1”socket remove the spindle nut
and washer. Retain hardware for reuse.
6. Slide the rotor off the spindle shaft. Make sure to keep the bearings inside the rotor. See Photo 5 & 6.
PHOTO 1 PHOTO 2
PHOTO 3 PHOTO 4
PHOTO 5 PHOTO 6
INSTALLATION INSTRUCTIONS
