17 Using a flat head screw driver remove the plastic cover on the front frame rail. See Photo 9. Using a 21 mm socket
and 24 mm wrench remove the front and rear lower control arm bolts. Be careful the torsion bar will come out with
the control arm. See Photo 10. Remove the torsion bar. Scribe a mark on the torsion bar to note it indexing in rela-
tionship to the control arm. The bars are to be reinstalled in same relationship as removed.
18 Position a floor jack or jack stand under the differential
to allow the differential bolts to be removed.
19 Using a 15 mm socket and 18 mm wrench remove the
passenger side upper bolt as shown in Photo 11 that
secures the differential to the frame. Retain the stock
hardware for reuse.
20. Using a 15mm socket and 18mm wrench remove the
driver side upper and lower differential bolts that se-
cure the differential to the frame. See Photo 12 & 13.
Retain the stock hardware for reuse.
21. Using a 15 mm socket remove the bolts securing the rear
cross-member to the frame as shown in Photo 15 and
remove from the vehicle.
Photo 9 Photo 10
Photo 11
Photo 12 Photo 13
Photo 15
