Rough Country 243.20 - Manual (Page 6)

6. Remove the sway-bar using a 13mm socket a pair vise grips on the lower control arm. A 10mm socket and 15mm
wrench on the frame. See Photo 7 & 8.
7. Remove the abs and brake line from upper control arm using two 13mm wrenches
8.
Using a 10mm wrench remove the abs line from the ball joint mount. See Photo 9.
9. Remove tie rod using a 19mm wrench and use a hammer to strike the side of the knuckle to dislodge the taper on
the tie rod. See Photo 10.
10. Remove brake caliper bolts using a 18mm socket. See Photo 11.
11. Remove the brake line bracket using a 13mm wrench on the frame
12. Remove the cotter pin and then the nut on the upper ball joint using a 22mm wrench. Use a hammer to strike the
side of the knuckle to dislodge the taper on the upper ball joint. See Photo 12.
Photo 7 Photo 8
Photo 9 Photo 10
Photo 11 Photo 12
