972H Wheel Loader specifications
General Purpose
Rock
Heavy-Duty
Waste
Quick Coupler Buckets
Bucket
Rock Bucket
Bucket
Teeth and
Bolt-On
Teeth and Teeth and
Bolt-On
Change
Teeth
Segments Edges Segments Segments Edges in
Specs
Rated Bucket Capacity (§)
m
3
3.95 4.15 4.15 4.00 4.00 6.50
yd
3
5.25 5.50 5.50 5.25 5.25 8.50
Struck Capacity (§)
m
3
3.43 3.60 3.60 3.45 3.45 5.60
yd
3
4.49 4.71 4.71 4.52 4.52 7.28
Width (§)
mm
3306
3306
3220
3270
3270
3355
ft/in
10'10" 10'10" 10'7" 10'9" 10'9" 11'0"
Dump Clearance at Full Lift
mm
3068
3068
3219
3075
3075
3212
335.75
and 45º Discharge (§)
ft/in
10'1"
10'1"
10'7"
10'1"
10'1"
10'6"
1'1"
Reach at Full Lift
mm
1474
1474
1335
1603
1603
1138
23.16
and 45º Discharge (§)
ft/in
4'10"
4'10"
4'5"
5'3"
5'3"
3'9"
1"
Reach with Lift Arm Horizontal
mm
3163
3163
2958
3244
3244
2845
309
and Bucket Level (§)
ft/in
10'5"
10'5"
9'8"
10'8"
10'8"
9'4"
1'0"
Digging Depth (§)
mm
67
94
94
98
98
113
-4.54
in
2.64 3.70 3.70 3.86 3.86 4.45 -0.1"
Overall
Length
mm
9419 9419 9196 9488 9488 9096 334.79
ft/in
30'11" 30'11" 30'2" 31'2" 31'2" 29'10" 1'1"
Overall Height with Bucket
mm
6035
6035
6035
6067
6394
6722
335.75
at Full Raise
ft/in
19'10"
19'10"
19'10"
19'11"
21'0"
22'1"
1'1"
Loader Clearance Circle with
mm
15 158
15 158
14 946
15 159
15 159
15 022
330.32
Bucket in Carry Position (§)
ft/in
49'9"
49'9"
49'0"
49'9"
49'9"
49'3"
1'1"
Static Tipping Load Straight *
kg
18 387
17 996
18 221
18 618
18 483
19 458
-1802
lb
40,543
39,681
40,177
41,053
40,755
42,905
-3,973
Static Tipping Load
kg
16 256
15 883
16 107
16 415
16 281
17 153
-1643
Full 37º Turn
lb
35,844
35,022
35,516
36,195
35,900
37,822
-3,623
Breakout Force ** (§)
kN
229
214
216
214
213
236
-7
lb
51,525
48,150
48,600
48,150
47,925
53,100
-1,654
Operating Weight * (§)
kg
25 412
25 603
25 436
25 901
26 075
26 051
74
lb
56,033
56,455
56,086
57,112
57,495
57,442
163
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers, including SAE Standard J732C
governing loader ratings.
* Static tipping loads and operating weights shown are based on standard machine configuration with 26.5R25 L-4 Firestone tires, full fuel tank, coolants,
lubricants, air conditioner, ride control, power train guard, metal roading fenders and operator.
** Measured 102 mm (4.0") behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732C.
High Lift
