22 972H Wheel Loader specifications
Material Handling Buckets
Teeth and Bolt-On Teeth and Bolt-On
Bucket Teeth Segments Edges Teeth Segments Edges
Rated Bucket Capacity (§) m 3 4.00 4.30 4.30 4.50 4.70 4.70
yd 3 5.25 5.50 5.50 5.75 6.00 6.00
Struck Capacity (§) m 3 3.51 3.66 3.66 3.88 4.03 4.03
yd 3 4.59 4.78 4.78 5.07 5.27 5.27
Width (§) mm 3306 3306 3220 3306 3306 3220
ft/in 10'10" 10'10" 10'7" 10'10" 10'10" 10'7"
Dump Clearance at Full Lift mm 3065 3065 3228 3001 3001 3164
and 45º Discharge (§) ft/in 10'1" 10'1" 10'7" 9'10" 9'10" 10'5"
Reach at Full Lift mm 1284 1284 1157 1348 1348 1221
and 45º Discharge (§) ft/in 4'3" 4'3" 3'10" 4'5" 4'5" 4'0"
Reach with Lift Arm Horizontal mm 3052 3052 2847 3142 3142 2937
and Bucket Level (§) ft/in 10'0" 10'0" 9'4" 10'4" 10'4" 9'8"
Digging Depth (§) mm 58 88 88 58 88 88
in 2.28 3.46 3.46 2.28 3.46 3.46
Overall Length mm 9304 9304 9080 9394 9394 9170
ft/in 30'6" 30'6" 29'9" 30'10" 30'10" 30'1"
Overall Height with Bucket mm 6071 6071 6071 6155 6155 6155
at Full Raise ft/in 19'11" 19'11" 19'11" 20'2" 20'2" 20'2"
Loader Clearance Circle with mm 15 091 15 091 14 880 15 141 15 141 14 929
Bucket in Carry Position (§) ft/in 49'6" 49'6" 48'10" 49'8" 49'8" 49'0"
Static Tipping Load Straight * kg 18 862 18 467 18 676 18 611 18 216 18 430
lb 41,591 40,720 41,181 41,037 40,166 40,638
Static Tipping Load kg 16 684 16 306 16 515 16 446 16 069 16 283
Full 37º Turn lb 36,788 35,955 36,416 36,263 35,432 35,904
Breakout Force ** (§) kN 254 237 239 236 221 223
lb 57,150 53,325 53,775 53,100 49,725 50,175
Operating Weight * (§) kg 25 535 25 726 25 559 25 646 25 837 25 670
lb 56,305 56,726 56,358 56,549 56,971 56,602
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers, including SAE Standard J732C
governing loader ratings.
* Static tipping loads and operating weights shown are based on standard machine configuration with 26.5R25 L-4 Firestone tires, full fuel tank, coolants,
lubricants, air conditioner, ride control, power train guard, metal roading fenders and operator.
** Measured 102 mm (4.0") behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732C.
Operating Specifications
