20 972H Wheel Loader specifications
Operating Specifications
General Purpose Buckets
Teeth and Bolt-On Teeth and Bolt-On
Bucket Teeth Segments Edges Teeth Segments Edges
Rated Bucket Capacity (§) m 3 3.80 4.00 4.00 4.00 4.30 4.30
yd 3 5.00 5.25 5.25 5.25 5.50 5.50
Struck Capacity (§) m 3 3.28 3.43 3.43 3.43 3.62 3.62
yd 3 4.29 4.48 4.48 4.48 4.73 4.73
Width (§) mm 3145 3145 3059 3306 3306 3220
ft/in 10'4" 10'4" 10'0" 10'10" 10'10" 10'7"
Dump Clearance at Full Lift mm 3157 3157 3309 3157 3157 3309
and 45º Discharge (§) ft/in 10'4" 10'4" 10'10" 10'4" 10'4" 10'10"
Reach at Full Lift mm 1386 1386 1246 1386 1386 1246
and 45º Discharge (§) ft/in 4'7" 4'7" 4'1" 4'7" 4'7" 4'1"
Reach with Lift Arm Horizontal mm 3037 3037 2832 3037 3037 2832
and Bucket Level (§) ft/in 10'0" 10'0" 9'4" 10'0" 10'0" 9'4"
Digging Depth (§) mm 58 88 88 58 88 88
in 2.28 3.46 3.46 2.28 3.46 3.46
Overall Length mm 9289 9289 9065 9289 9289 9065
ft/in 30'6" 30'6" 29'9" 30'6" 30'6" 29'9"
Overall Height with Bucket mm 6075 6075 6075 6075 6075 6075
at Full Raise ft/in 19'11" 19'11" 19'11" 19'11" 19'11" 19'11"
Loader Clearance Circle with mm 14 937 14 937 14 725 15 082 15 082 14 872
Bucket in Carry Position (§) ft/in 49'0" 49'0" 48'4" 49'6" 49'6" 48'9"
Static Tipping Load Straight * kg 19 169 18 805 18 989 19 191 18 796 19 009
lb 42,268 41,465 41,871 42,316 41,445 41,915
Static Tipping Load kg 16 969 16 625 16 808 16 981 16 604 16 817
Full 37º Turn lb 37,417 36,658 37,062 37,443 36,612 37,081
Breakout Force ** (§) kN 258 241 242 258 240 242
lb 58,050 54,225 54,450 58,050 54,000 54,450
Operating Weight * (§) kg 25 424 25 576 25 436 25 488 25 679 25 512
lb 56,060 56,395 56,086 56,201 56,622 56,254
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers, including SAE Standard J732C
governing loader ratings.
* Static tipping loads and operating weights shown are based on standard machine configuration with 26.5R25 L-4 Firestone tires, full fuel tank, coolants,
lubricants, air conditioner, ride control, power train guard, metal roading fenders and operator.
** Measured 102 mm (4.0") behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732C.
1400
yd 3 m 3
kg/m 3
5.25
5.5
5.75
6.0
4.0
4.3
4.5
4.6
1600 1800 2000 2200
Bucket Selection Guide
1200 1000
2250 2500 2750 3000 3250 3500 3750 lb/yd 3
Material Density
% = Bucket Fill Factor
115% 100% 95%
2000 1800
