972H Wheel Loader specifications
General Purpose Buckets
Teeth and
Bolt-On
Teeth and
Bolt-On
Bucket
Teeth
Segments
Edges
Teeth
Segments
Edges
Rated Bucket Capacity (§)
m
3
4.30 4.50 4.50 4.40 4.60 4.60
yd
3
5.50 5.75 5.75 5.75 6.00 6.00
Struck Capacity (§)
m
3
3.67 3.82 3.82 3.85 4.00 4.00
yd
3
4.80 5.00 5.00 5.04 5.23 5.23
Width (§)
mm
3306
3306
3220
3306
3306
3220
ft/in
10'10" 10'10" 10'7" 10'10" 10'10" 10'7"
Dump
Clearance
at
Full
Lift
mm
3115 3115 3268 3100 3100 3252
and 45º Discharge (§)
ft/in
10'3" 10'3" 10'9" 10'2" 10'2" 10'8"
Reach
at
Full
Lift
mm
1413 1413 1274 1431 1431 1291
and 45º Discharge (§)
ft/in
4'8" 4'8" 4'2" 4'8" 4'8" 4'3"
Reach with Lift Arm Horizontal
mm
3087
3087
2882
3109
3109
2904
and Bucket Level (§)
ft/in
10'2" 10'2" 9'5" 10'2" 10'2" 9'6"
Digging Depth (§)
mm
58 88 88 67 97 97
in
2.28 3.46 3.46 2.64 3.82 3.82
Overall
Length
mm
9339 9339 9115 9368 9368 9144
ft/in
30'8" 30'8" 29'11" 30'9" 30'9" 30'0"
Overall
Height
with
Bucket
mm
6122 6122 6122 6015 6015 6015
at
Full
Raise
ft/in
20'1" 20'1" 20'1" 19'9" 19'9" 19'9"
Loader Clearance Circle with
mm
15 110
15 110
14 899
15 130
15 130
14 919
Bucket in Carry Position (§) ft/in
49'7" 49'7" 48'11" 49'8" 49'8" 48'11"
Static Tipping Load Straight *
kg
18 965
18 569
18 781
19 258
18 854
19 067
lb
41,818
40,945
41,412
42,464
41,573
42,043
Static Tipping Load
kg
16 774
16 396
16 608
17 076
16 691
16 903
Full 37º Turn
lb
36,987
36,153
36,621
37,653
36,804
37,271
Breakout Force ** (§)
kN
247
231
232
244
229
230
lb
55,575
51,975
52,200
54,900
51,525
51,750
Operating Weight * (§)
kg
25 542
25 733
25 566
25 124
25 315
25 148
lb
56,320
56,741
56,373
55,398
55,820
55,451
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers, including SAE Standard J732C
governing loader ratings.
* Static tipping loads and operating weights shown are based on standard machine configuration with 26.5R25 L-4 Firestone tires, full fuel tank, coolants,
lubricants, air conditioner, ride control, power train guard, metal roading fenders and operator.
** Measured 102 mm (4.0") behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732C.
