966H Wheel Loader specifications
Heavy Duty
Quick Coupler General Purpose Buckets
Rock Buckets
Rock Buckets
Teeth and
Bolt-On
Bolt-On
Teeth and
Teeth and
Bucket
Teeth
Segments
Edges
Edges
Segments
Segments
Rated Bucket Capacity (§)
m
3
3.65 3.85 3.85 3.50 3.50 3.50
yd
3
4.75 5.00 5.00 5.00 5.00 5.00
Struck Capacity (§)
m
3
3.16 3.31 3.31 2.99 2.99 2.99
yd
3
4.13 4.33 4.33 3.91 3.91 3.91
Width (§)
mm
3145
3145
3059
3283
3270
3270
ft/in
10'4" 10'4" 10'0" 10'9" 10'9" 10'9"
Dump
Clearance
at
Full
Lift
mm
2843 2843 2995 3114 2965 2965
and 45º Discharge (§)
ft/in
9'4" 9'4" 9'10" 10'3" 9'9" 9'9"
Reach
at
Full
Lift
mm
1520 1520 1380 1423 1612 1612
and 45º Discharge (§)
ft/in
5'0" 5'0" 4'6" 4'8" 5'3" 5'3"
Reach with Lift Arm Horizontal
mm
3068
3068
2863
2799
3004
3004
and Bucket Level (§)
ft/in
10'1" 10'1" 9'5" 9'2" 9'10" 9'10"
Digging Depth (§)
mm
88 118 118 113 118 118
in
3.46 4.65 4.65 4.45 4.65 4.65
Overall
Length
mm
9214 9214 8988 8921 9169 9169
ft/in
30'3" 30'3" 29'6" 29'3" 30'1" 30'1"
Overall
Height
with
Bucket
mm
5762 5762 5762 5736 5736 6063
at
Full
Raise
ft/in
18'11" 18'11" 18'11" 18'10" 18'10" 19'11"
Loader Clearance Circle with
mm
14 853
14 853
14 645
14 814
14 935
14 935
Bucket in Carry Position (§)
ft/in
48'9" 48'9" 48'1" 48'7" 49'0" 49'0"
Static Tipping Load Straight *
kg
16 965
16 634
16 797
17 380
17 244
17 122
lb
37,408
36,678
37,037
38,323
38,023
37,754
Static Tipping Load
kg
15 103
14 787
14 950
15 439
15 303
15 180
Full 37º Turn
lb
33,302
32,605
32,965
34,043
33,743
33,472
Breakout Force ** (§)
kN
179
168
169
178
180
179
lb
40,275
37,800
38,025
40,050
40,500
40,275
Operating Weight * (§)
kg
23 516
23 668
23 528
23 867
23 969
24 129
lb
51,853
52,188
51,879
52,627
52,852
53,204
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers, including SAE Standard J732C
governing loader ratings.
* Static tipping loads and operating weights shown are based on standard machine configuration with 26.5R25 L-4 Firestone tires, roading fenders. powertrain
guard, full fuel tank, coolants, lubricants, air conditioner and operator.
** Measured 102 mm (4.0") behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732C.
