18 966H Wheel Loader specifications
Hydraulic System
Bucket/Work Tool System – 305 L/min 80.6 gal/min
Pump Output
Steering System Pump Type Piston
Hydraulic Cycle Time – Raise 5.9 Seconds
Hydraulic Cycle Time – Dump 1.6 Seconds
Hydraulic Cycle Time – Lower, 2.4 Seconds
Empty, Float Down
Hydraulic Cycle Time – Total 9.9 Seconds
• Implement System (Standard), Piston Pump – Rated at 2,100 rpm
and 1,000 psi (6900 kPa).
• Cycle time with rated payload
Brakes
Brakes Meets required standards.
• Meet OSHA, SAE J1473 OCT90 and ISO 3450-1985 standards.
Axles
Front Fixed front
Rear Oscillating ± 13°
Maximum Single-Wheel Rise 502 mm 19.8 in
and Fall
Tires
Tires Choose from a variety of tires to
match your application.
• Choice of:
26.5R25, L-2
26.5R25, L-3 (XHA)
26.5R25, L-5 (VSDL)
26.5-25, L-3 (SRG, SHRL)
750/65R25, L-3
• NOTE: In certain applications (such as load and carry)
the loader’s productive capabilities might exceed the tires’
tonnes-km/h (ton-mph) capabilities. Caterpillar recommends
that you consult a tire supplier to evaluate all conditions before
selecting a tire model. The 26.5-25 size range and other special
tires are available on request.
Engine
Engine Model Cat ® C11 ACERT™
Gross Power – SAE J1995 213 kW 286 hp
Net Power – ISO 9249 195 kW 262 hp
Net Power – SAE J1349 193 kW 259 hp
Net Power – 80/1269/EEC 195 kW 262 hp
Peak Torque (Net) @ 1,400 rpm 1215 N•m 896 ft-lb
Bore 130 mm 5.12 in
Stroke 140 mm 5.51 in
Displacement 11.1 L 677 in 3
• Caterpillar engine with ACERT™ Technology – EPA Tier III,
EU Stage III Compliant
• These ratings apply at 1,800 rpm when tested under the
specified standard conditions.
• Rating for net power advertised based on power available
when the engine is equipped with alternator, air cleaner,
muffler and on-demand hydraulic fan drive at maximum
fan speed.
Weights
Operating Weight 23 698 kg 52,254 lb
• For 4.25 m 3 (5.5 yd 3 ) general purpose bucket with BOCE
Buckets
Bucket Capacities 3.4-4.2 m 3 4.5-5.5 yd 3
Max Bucket Capacity 4.2 m 3 5.5 yd 3
Operating Specifications
Static Tipping Load, Full Turn 15 474 kg 34,120 lb
Breakout Force 188 kN 42,300 lb
• For 4.25 m 3 (5.5 yd 3 ) general purpose bucket with BOCE
Transmission
Forward 1 6.7 km/h 4.2 mph
Forward 2 12.6 km/h 7.8 mph
Forward 3 22.1 km/h 13.7 mph
Forward 4 37.4 km/h 23.2 mph
Reverse 1 7.4 km/h 4.6 mph
Reverse 2 13.9 km/h 8.6 mph
Reverse 3 24.3 km/h 15.1 mph
Reverse 4 37.4 km/h 23.2 mph
• Maximum travel speeds (26.5-25 tires).
