Technical data
Trebing & Himstedt Prozeßautomation GmbH & Co. KG | TH LINK
34
Technical data
Electrical data
Nominal supply voltage
(limit values)
VDC 24 (19.2...28.8)
Current consumption max. mA 190
Protection class IP 20
Operating conditions
Ambient temperature range °F 32...122
Relative humidity % 20...80 (no condensation)
Case data
Dimensions W × H × D in 0.9 x 3.9 x 4.5
Weight (approx.) l 0.3
PROFIBUS interface
Interface Type RS 485
Transmission rate bps 9,600...12M
Sub-D plug pin assignment Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9 not assigned
not assigned
B line data+ (RxD/TxD-P)
RTS
GND (0 V)
Potential (+5 VDC)
not assigned
A line data– (RxD/TxD-N)
not assigned
Other
Ethernet connection Type RJ-45 (10Base-T/100Base-TX)
Certificates CE, UL
1 5
6 9
