Design of the TH LINK
TH LINK | Trebing & Himstedt Prozeßautomation GmbH & Co. KG
11
Fig. 1: TH LINK (front and side view)
TH LINK
Trebing & Himstedt Prozeßautomation GmbH & Co. KG
www.t-h.de
Made in Germany
Part No.: 10003006
HW-Release: 2.0
Serial No.:
000000
Temperature: 0 to +50 °C
Current: 190 mA max.
Power Supply: 19.2 to 28.8 V DC
ETH: Ethernet (green/red)
RUN: OK (green) | Error (red)
BUS: PROFIBUS (green/red)
24 V DC
+ –
ETH
RUN
BUS
PR
O
F
IB
U
S
TR
E
B
IN
G
+
H
IMS
TE
D
T
A B C D
[1]
[2]
[3]
[5]
[7]
[4]
[6]
[8]
