Connecting to Ethernet
TH LINK | Trebing & Himstedt Prozeßautomation GmbH & Co. KG
15
Uninstalling the TH LINK
1. Remove the connected supply and signal lines (Ethernet,
PROFIBUS, voltage).
2. Place the screwdriver into the stop lever on the TH LINK
(see figure 2).
3. Press the screwdriver in the direction of the TH LINK and
simultaneously swing the device off the top-hat rail.
Connecting to Ethernet
– Insert the patch cable plug (RJ-45, not included in the scope of
delivery) into the Ethernet socket (see figure 1 no. [1]) on the
TH LINK until the plug locks into place.
– The green LED on the Ethernet socket lights as soon as the
TH LINK is energized and an Ethernet network is available.
