5 Setup - Sensors up to software 3.99
PLICSCOM •
36433-EN-130228
•
PA-Out (value after passing the function block): PA output
•
Temperature
In the menu item "Display" you can define which value should be
indicated on the display.
Displayed value
PA-Out
Profibus transmits two values cyclically. The first value is determined
in the menu item "Channel". The selection of the additional cyclical
value is made in the menu item "Additional PA value".
The following values are available with radar, guided microwave and
ultrasonic sensors:
•
SV1 (Secondary Value 1): Percentage value after the adjustment
•
SV2 (Secondary Value 2): Distance value before the adjustment
•
PV (Primary Value): Linearised percentage value
With pressure transmitters the following values are available:
•
SV1 (Secondary Value 1): Pressure or height value before adjust-
ment
•
SV2 (Secondary Value 2): Percentage value after the adjustment
•
PV (Primary Value): Linearised percentage value
Additional PA value
Here, you determine the unit and scaling for PA-Out. These settings
also apply to the values displayed on the display and adjustment
module if in the menu item "Displayed value" PA-Out was selected.
The following displayed values are available in "Out-Scale unit":
•
Pressure (only with pressure transmitters)
•
Height
•
Ground
•
Flow
•
Volume
•
Others (no unit, %, mA)
In the menu item "PV-Out-Scale", the requested numerical value with
decimal point is entered for 0 % and 100 % of the measured value.
Out-Scale-Unit
Service/Additional PA
value
Service/Determine Out-
Scale
