VEGASON 71 - D 15
4.2 Mode range, general parameter adjustment, mode
0 - 00 0 - 00 0 - 00 0 - 00 0 - 00
…
0 - 99 0 - 99 0 - 99 0 - 99 0 - 99
Function Mode-no. Mode description Parameter Page
(bold = factory setting)
0 - 00 Software version .................................................... z.B. 48.94
0 - 01 … 10 not coordinated ...................................................... – – – –
Adjustment 0 - 11 Empty adjustment
-
distance in m ..................................................... 5.000 m … 0.000 m
- level in % ........................................................... 0.0 0.0 0.0 0.0 0.0 … 80.0 P. 18
0 - 12 Full adjustment
-
distance in m ..................................................... 0.000 m … 5.000 m
- level in % ........................................................... 100.0 100.0 100.0 100.0 100.0 … 20.0
Display Allocation of a multiplication factor
function
0 - 13
- relating to 0 % ...................................................
0000 0000 0000 0000 0000
…
9999
0 - 14 - relating to 100 % ............................................... 0000 … 1000 1000 1000 1000 1000 … 9999
0 - 15 Measuring unit P. 23
- distance in m ..................................................... 1 11 11
- level in % ........................................................... 2
- scaled value ...................................................... 3
0 - 16 Decimal point ......................................................... 0.000 … 000.0 000.0 000.0 000.0 000.0 … 0000
0 - 17 Integration time ......................................................
0 0 0 0 0 … 900 P. 24
Lineari- 0 - 18 Linearization curves
zation - linear ................................................................. 1
- not coordinated ................................................. 2
- not coordinated ................................................. 3
- individually programmable curve 4 .................... 4
- individually programmable curve 5 ....................
5
- individually programmable curve 6 .................... 6
- root function Q = K x h 0,5 ................................... 7
- linear function Q = K x h 1,0 ................................. 8 8 8 8 8 P. 20
- Venturi flume
rectangular flume
rectangular weir
trapezoidal weir Q = K x h
1,5 ..............................
9
- Palmer Bowlus Flume Q = K x h 1,86 ................... 10
- quadratic function Q = K x h 2,0
................................................ 11
- V-Notch
Q = K x h
2,5 ........................................................
12
0 - 19 … 52 not coordinated ...................................................... – – – –
Level 0 - 53 Coordination
module - measuring result in m ........................................
1
- measuring result in % ........................................
2 2 2 2 2
0 - 54 not coordinated ...................................................... – – – – P. 32
Switching command
0 - 55 - on ...................................................................... 0.000 m … 5.000 m
0 - 56 - off ...................................................................... 0.000 m … 5.000 m
0 - 57
not coordinated ...................................................... – – – –
4 Set-up
Relay
output 1
