Installation Guide
Power Monitoring
E51H2A, E51H5A
TM
R/W
R=read only; R/W=read or write
NV
Value is stored in non-volatile memory. The value are still available if the meter experiences a power loss and reset.
Units
Lists the physical units that a register holds.
Legend
Device Object
Property
R/W
NV
Value Returned
Additional information
Object_Identifier
R/W
NV
Device
n is the 7 digit ID # set in the ID1 & ID2 setup screens on the meter. The BACnet Device
ID is a decimal number from 1 to 4,193,999 that can be entered or viewed on the user
screens or through this property. The default value set at the factory is a psuedo-
random number from 1,000,000 to 3,097,151 to reduce the likelihood of conflicts if
multiple units are installed using their default IDs.
Object_Type
R
NV
Device (8)
Object_Name
R
NV
Veris E51 Series Energy Meter - S/N: number> Vendor_Name R NV Veris Industries, LLC Vendor_Identifier R NV 133 Model_Name R NV E51HxA Energy Meter Firmware_Revision R NV “xyyy”. decimal point between the first two digits (x.yyy) Application_Software_ Version R NV “RS= xyyy, OS=xyyy, BACnet Gateway=xyyy” Location R/W NV Limted to 64 Characters - Default value is “Installed location not yet identified” Description R NV Veris E51HxA DIN-Rail Energy Meter S/N: Protocol_Version R NV 1 BACnet Protocol Version 1 Protocol_Revsion R NV 4 BACnet Protocol Revision 4 Local_Date R Date Set via BACnet Time Synchronization only - reverts to Jan 1, 2000 if control power drops Local_Time R Time Set via BACnet Time Synchronization only - reverts to 12:00:00 AM if control power drops Segmentation_Supported R NV NO_SEGMENTATION (3) Segmentation is not supported Max_Master R/W NV 1-127 (Factory Default is 127) Highest possible MAC Address for Master nodes on the local MS/TP network Max_Info_Frames R NV 1 Maximum number of information frames allowed before passing the MS/TP token Max_APDU_Length_Accepted R NV 480 APDU_Timeout R NV 60000 Number_of_APDU_Retries R NV 0 System_Status R NV Operational (0) Protocol_Sevices_Supported R NV 0b0000000000001011010000000000000 011110000 Protocol_Object_Types_Supported R NV 0b1011000010000000000010000000000
This is the BACnet processor firmware version in the format
The format
