V100D INSTALLATION GUIDE
WIRING EXAMPLE
Nipple mount directly to a panel
Nipple mount to any 2x or 4x electrical box
To Load
To Controls
COIL
CONT
ACTS
To Load
To Controls
Wire
Nut
CO
IL
CONTACTS
WIRING COLOR CODES
CONTACT AND COIL SPECIFICATIONS
Pull in Voltage AC DC
10-30V..................................... 8 9
120V........................................ 78
Drop Out Voltage
AC DC
10-30V..................................... 2 3
120V........................................ 18
Voltage
Coil Current
AC DC
10V.......................................... 25mA 14mA
12V.......................................... 25mA 14mA
24V.......................................... 31mA 16mA
30V.......................................... 39mA 18mA
120V........................................ 22mA -
TYPICAL COIL PERFORMANCE
CONTACT RATINGS
Resistive.............. 10A@277VAC, 28VDC
Motor.................... 120VAC, 1/3HP N.O. & 1/6HP N.C.
240VAC, 1/3HP N.O. & 1/6HP N.C.
277VAC, 1/4HP N.O. & 1/8HP N.C.
Pilot Duty............. 277VAC, (1.7A), 480VA N.O.
Ballast.................. 277VAC, 1.7A
Tungsten............... 120VAC, TV3 N.O. TV2 N.C.
Gold Flash............. Yes
Relay 1
Relay 2
LED CONFIGURATION
N.C.
Common
10-30VAC/DC
120VAC
HI
wht/black
LOW
wht/blue
COMM
wht/yellow
Common
N.O.
CONTACT OUTPUT CONTROL SYSTEM INPUT
White
YELLOW
White
White
ORANGE
blac
k
blac
k
blue blue
yello
w
yello
w
blac
k
120VAC N.C.
Common
N.O.
10-30VAC/DC
COMMON
HI
wht/red
LOW
grey/wht
COMM
wht/violet
CONTACT OUTPUT CONTROL SYSTEM INPUT
REL
AY 2
REL
AY 1
Relay 2
Relay 1
